Sleepy Creek Coil Spring Traps

Coilspring Traps

#1 Coil Spring Trap

• Frame - One-piece construction, 1/8" thick with center mounted chain.

• Pan - One-piece construction, rectangular style with crimped bolt and nut.

• Standard Jaw - Four-inch spread.

• Double Jaw - Four-inch spread.

• Chain - #2/0 double link with two swivel points, ring and drowner.

• Springs - Heavy duty 11-guage spring wire.

• Levers - Heavy duty 0.62" thick steel.

• Weight - 14 ounces

Target Species: Muskrat, Mink, Weasel, Fisher, Squirrel, Opossum and Skunk.

#1-1/2 Coil Spring Trap

• Frame - Two-piece 1/8" thick x 7/8" wide construction. Center mounted chain.

• Pan Post - 1/8" thick and welded through the cross.

• Standard Jaw - 4-7/8" jaw spread, 5/32" x 1/2" with corner radius to prevent cutting.

• Offset Jaw - 5" jaw spread, with a face that averages nearly twice that of the standard jaw.

• Chain - #2/0 double link, with two swivel points, ring and drowner.

• Pan - Two-piece construction with crimped bolt and nut.

• Springs - Heavy duty 10-gauge spring wire.

• Levers - Heavy duty .075" thick steel.

• Weight - 1 pound 5.44 ounces

Target Species: Fox, Fisher, Marten, Mink, Muskrat, Nutria, Opossum, Raccoon, Skunk and Woodchuck.

#1-1/2 Double Jaw Coil Spring Trap

Jaw Spread: 4-7/8", 5/32" x 1/2" with corner radius to prevent cutting. The wire form is .162 diameter wire offset from the inside jaw edge and welded at the top.

#1-3/4 Coil Spring Trap

•Frame - Two-piece 1/8" thick x 7/8" wide construction. Base is reinforced with 1/16" thick chain strap with center mounted chain.

• Pan Post - 1/8" thick and welded through the cross.

• Standard Jaw - 5-3/8" spread, 5/32" x 1/2" with corner radius to prevent cutting.

• Offset Jaw - 5-9/16" spread. Face averages nearly twice that of standard jaw.

• Chain - #2/0 double link with three swivel points.

• Pan - Two-piece construction with crimped bolt and nut.

• Springs - Heavy duty 9-gauge spring wire.

• Levers - Heavy duty .075" thick steel.

• Weight - 1 pound 7 ounces

Target Species: Badger, Bobcat, Coyote, Fisher, Fox, Lynx, Nutria, Otter and Raccoon.

#1-3/4 Coil Spring Trap - Round Pan

• Frame - Two-piece 1/8" thick x 7/8" wide construction. Base is reinforced with 1/16" thick chain strap with center mounted chain.

• Pan Post - 1/8" thick and welded through the cross.

• Standard Jaw - 5-3/8" spread, 5/32" x 1/2" with corner radius to prevent cutting.

• Offset Jaw - 5-9/16" spread. Face averages nearly twice that of standard jaw.

• Chain - #2/0 double link with three swivel points.

• Pan - Two-piece construction with crimped bolt and nut.

• Springs - .148 diameter hard drawn MB spring wire on regular jaw; .156 diameter on offset jaw.

• Levers - Heavy duty .075" thick steel.

• Weight - 1 pound 7 ounces

#1-3/4 Coil Spring Trap 4x4

•Frame - Two-piece 1/8" thick x 7/8" wide construction. Base is reinforced with 1/16" thick chain strap with center mounted chain.

• Cross - Integral gusseted pan post with installed pan post hardware.

• Standard Jaw - 5-3/8" spread, 5/32" x 1/2" with corner radius to prevent cutting.

• Offset Jaw - 5-9/16" spread. Face averages nearly twice that of standard jaw.

• Chain - #2/0 double loop with three swivel points. Standard jaw trap has standard chain assembly; offset jaw trap has short chain assembly.

• Pan - Straddle pan has a notch to allow for visual dog engagement and is attached with 8/32 brass bolt and nut..

• Springs - 4 coils are wound out of .125 diameter music wire for holding power..

• Levers - Heavy duty .075" thick steel.

• Weight - 1 pound 9 ounces, standard; 1 pound 8 ounces, offset.

#3 Coil Spring Trap

• Frame - Two-piece, 1/8" thick x 1" wide with reinforcing D-ring chain strap and 1" D-ring.

• Cross - Integral gussetted pan post with a hole for an adjustable pan stop.

• Standard Jaw - 5-13/16" spread, 5/32" x 9/16" with corner radius to prevent cutting.

• Offset Jaw - 6" spread, the face averages nearly twice that of the standard jaw.

• Chain - #2 machine chain twist link, center mounted with three swivel points.

• Pan - One-piece construction with visual dog engagement and crimped bolt and nut.

• Springs - Heavy duty 8-gauge spring wire.

• Levers - Heavy duty .090" thick steel set at a 60-degree angle.

• Weight - 2 pounds .32 ounces

Target Species: Badger, Beaver, Bobcat, Coyote and Lynx.

#4 Coil Spring Trap

• Frame - Two-piece, 1/8" thick x 1" wide with reinforcing D-ring chain strap and 1" D-ring.

• Cross - Integral gusseted pan post with a hole for an adjustable pan stop.

• Standard Jaw - 6-5/16" spread, 5/32" x 9/16" with corner radius to prevent cutting.

• Offset Jaw - 6-1/2" spread. The face averages nearly twice that of the standard jaw.

• Chain - #2 machine chain twist link, center mounted with three swivel points.

• Pan - One-piece construction with visual dog engagement and crimped bolt and nut.

• Springs - Heavy duty 8-gauge spring wire.

• Levers - Heavy duty .090" thick steel set at a 60-degree angle.

• Weight - 2 pounds 1.25 ounces

Target Species: Badger, Beaver, Bobcat, Coyote, Lynx and Otter.

#440 Nitro Offset

• Frame - Two-piece, 1/8" thick x 1" wide with reinforcing D-ring chain strap and 1" D-ring.

• Cross - Integral gusseted pan post with a hole for an adjustable pan stop.

• Standard Jaw - 6-5/16" spread, 5/32" x 9/16" with corner radius to prevent cutting.

• Offset Jaw - 6-1/2" spread. The face averages nearly twice that of the standard jaw.

• Pan - One-piece construction with visual dog engagement and crimped bolt and nut.

• Springs - Heavy duty 8-gauge spring wire.

• Levers - Heavy duty .090" thick steel set at a 60-degree angle.

• Weight - 2 pounds

Target Species: Badger, Beaver, Bobcat, Coyote, Lynx and Otter.

#5 Wolf Trap-COMING SOON!!!

• Frame - 2-piece, 3/16"

thick x 1 ¼" wide. With

reinforced D-Ring Chain

Strap and 1¼" D-Ring

• Cross - 1-piece, 3/16" thick w/ staked pan post, and a adjustable pan stop, serialized on the end. (#'s 0001 - 0452)

• Jaw - 9" Spread, ¼" thk x 7/8" wide, w/ 3/8" cut in offset & teeth. Jaws are riveted between the chain strap & frame.

• Chain - #2/0 Twist Link Machine Chain, Self-colored, w/4 swivel points & ring. Lift tested to 440 lbs.

• Pan - 1/8" x 3¼ Straddle Pan w/anti-lift stops & visual dog engagement. Attached with ¼ - 20 SS Bolt & Nyloc Nut.

• Springs - 135" thick, Heat-treated Spring Steel. Springs fold inside frame for easy carry and have Wolf stamped on each spring.

• Weight - 7 pounds 6 ounces

• Target Species - Wolf, Mountain Lion, ANTIFA Members
